Detachable garbage trucks (over 10T total mass) are used in conjunction with a split-type garbage compression station or an integrated garbage compression station.
1. Large tonnage (over 10T total mass) vehicles are used in conjunction with a split-type garbage compression station or an integrated garbage compression station. The hydraulic system is controlled by the operation button in the cab to realize the entire loading and unloading work cycle. The type garbage compression station provides hydraulic power and has a high degree of automation;
2. Small-tonnage (total mass below 10T) vehicles can be used together with garbage cans as a collection vehicle for loose garbage in living quarters such as cities, townships, towns, docks, etc., and can also be used for the transfer of garbage cans at fixed delivery points. fast;
3. One car can be equipped with multiple boxes, the vehicle and the box can be separated, the transfer efficiency is high, and the time is saved.
| Vehicle Model | CLY5023ZXXE5 | CLY5031ZXXE5 | CLY5031ZXXE5 | CLY5041ZXXE5 | CLY5042ZXXE5 | CLY5074ZXXE5 | CLY5076ZXXE5 | CLY5077ZXXE5 |
| Total Mass | 1990 | 2840 | 3495 | 4000 | 4495 | 7350 | 7360 | 7300 |
| Curb Weight/Rated Load Weight (kg) | 1050/810 | 1140/1570,1180/1530 | 1450/1915 | 2070/1800 | 2295/2070 | 2850/4305 | 2990/4240 | 2740/4430 |
| Chassis Model (Brand) | EQ1021TF53（Dongfeng Xiaokang） | SC1031GDD52（Changan） | SC1031GDD53（Changan） | HFC1042PW4K1B3ZV（JAC） | BJ1041V9JD5-A1（Fukuda） | SH1072ZFDCMZ（SAIC） | HFC1070P93K1C3ZV（JAC） | QL1070A5HAY（Qingling） |
| Engine Model and Power (kW) | BG1070(51) | DK12-10(65) | DK12-10(65) | 4A2-88C50(65) | 4J28TC5(81) | SOFIM8140.43DV(92) | WP3Q120E50(96) | 4KH1CN5HS(96) |
| Fuel Type | Gasoline | Gasoline | Gasoline | Diesel Fuel | Diesel Fuel | Diesel Fuel | Diesel Fuel | Diesel Fuel |
| Dimensions (L*W*H)（mm） | 4035,4110*1560*1900,1840 | 4045,4325*1520*1930 | 4630,4390*1580*1940 | 4546,4356*1650*2000 | 4920,4690*1920*2190 | 5546*1970*2261 | 5445*1900*2180 | 5415,5325*1900*2200 |
| Wheelbase（mm） | 2760 | 2700 | 2990 | 2600 | 2800/2600 | 3308 | 3360 | 3360 |
| Ability to Evoke（t） | 1 | 1/1.5 | 2 | 2 | 2 | 3 | 3 | 3 |
| Dump Tilt Angle | ≥48 | ≥48 | ≥48 | ≥48 | ≥48 | ≥48 | ≥48 | ≥48 |
